DONGFENG KC 6X2 Truck Chassis 245HP 18t Heavy-Duty Chassis for sale
6x2 | 245HP | Euro 6+ | D560 | 1 year
$ 3,900.00 ~ $ 4,600.00
Looking for a reliable, cost-effective 6X2 dump truck for your construction, mining, or aggregate transport business? The Dongfeng Tianjin KC 245HP 6X2 4.5m tipper truck delivers the perfect balance of power, payload, and affordability – engineered for the toughest job sites across Africa, Southeast Asia, South America, and the Middle East.
15.7-ton payload | Yuchai 245HP engine | Fast 10-speed transmission | Reinforced 300mm frame – Built for Africa, Southeast Asia, South America & Middle East jobsites
Main Features
YCS06245-60
10JS90A-B
Diesel
Drum Brake, ABS
15705 Kg
11.00R20 18PR
The Dongfeng 245hp 6X2 Truck Chassis is widely used in:
- 🏗️ Construction – sand, gravel, concrete aggregates
- ⛏️ Mining – ore, overburden, mine waste
- 🪨 Quarry – crushed stone, limestone
- 🛣️ Infrastructure – road building, dam construction, land development
Description
The Dongfeng Tianjin KC series is a flagship product line from Dongfeng Commercial Vehicle designed for the construction dump truck market, specifically targeting applications such as urban construction debris hauling, mining overburden removal, and the transport of sand and gravel. Equipped with a Yuchai National VI engine and a Fast 10-speed transmission, and featuring a 6x2 drive configuration and a 4.5-meter cargo bed, this model is precision-engineered for the short-to-medium-haul heavy-duty transport market. According to official specifications, the vehicle has a curb weight of 9.1 tons, a rated payload of 15.705 tons, and a gross vehicle weight (GVW) of 18 tons. Achieving a rated payload exceeding 15 tons within an 18-ton GVW limit results in an outstanding payload utilization coefficient, fully embodying the design philosophy of construction dump trucks: "hauling more and moving fast."
| Basic Configuration | Performance Parameter | ||
|---|---|---|---|
| Drive Type | 6x2 | Engine Model | YCS06245-60 |
| GVW | 18,000 Kg | Displacement | 6,230 ml |
| Wheelbase | 2600+1300 mm | Emission_std | Euro 6+ |
| Cab Style | D560 | Max Torque | 850 N·m |
| Frame | 300×90×(8+6)mm reinforced frame | Transmission | 10-speed Manual |
| Leaf Spring | 10 / 7 / 10+8 | Rear Axle Ratio | 5.92 |
| Front/Rear Axle | 6000/18000 kg | Max Speed | 89 km/h |
| Tyre | 11.00R20 18PR | Air Condition/AC | With AC |
| Fuel Tank Capacity | 200 L | Equipped With Spare Tire | With one spare tyre |
Additional information
MOQ: 1 unit
Delivery Time：Within 15 days in Stock; within 30 days out of stock
Payment Method: 30% deposit
Certifications: CCC, ISO9001, ISO14001
Stock ID: DFH3250BX5
Choosing the right Dongfeng 245hp 6X2 Truck Chassis is critical for your project. Check our expert guides:
